Description
Three-way L-port ball valve with 3/4" BSP female connections, designed for multi-directional flow control in pneumatic and hydraulic systems.
This compact brass valve provides reliable directional switching at pressures up to 40 bar and temperatures to 80°C. The L-port configuration enables simultaneous inlet and outlet connections with a common port, making it ideal for diverting or combining fluid streams. Nickel-chromium plating ensures corrosion resistance, while PTFE ball seats and Viton seals deliver long service life.
Key Features
- 3/4" BSP female threads on all three ports
- L-port configuration for multi-directional flow
- Nickel-chromium plated brass body
- PTFE ball seats for low friction operation
- Viton elastomer seals
- Full-flow 90° ball design
Specifications
- Port size: 3/4" BSP female
- Maximum pressure: 40 bar
- Maximum temperature: 80°C
- Port arrangement: L-type (3-way)
- Body material: Brass with nickel-chromium plating
- Seat material: PTFE
- Seal material: Viton
Applications
- Pneumatic and hydraulic fluid switching
- Circulation system diverters
- Process flow control and routing
- Plant machinery hydraulic circuits
- Industrial pump discharge redirection
