3/4" BSP Float Valve with Quick-Close Mechanism

Hydraulic water level regulator designed for tank and cistern applications, featuring instant close-off to eliminate pump stop-start cycling.

This float valve delivers rapid tank filling with high flow capacity and minimal pressure loss. The unique mechanism transitions instantly from fully open to fully closed, preventing repetitive pump cycling. A delayed re-start level of approximately 3 cm further reduces pump activation frequency when water is drawn from the tank.

Key Features

• Instant full open-to-closed transition eliminates pump cycling
• High flow rate with minimal pressure loss
• Adjustable float arm with 6 settings, extending up to 60 mm
• Operating pressure range 0.2–6 bar
• Polycarbonate body and float with stainless steel fasteners
• CE marked; temperature rated 0–50 °C operating

Specifications

• Connection: 3/4" BSP
• Operating pressure: 0.2–6 bar
• Burst pressure: >20 bar
• Operating temperature: 0–50 °C
• Storage temperature: −20–80 °C
• Float movement range: 0–180°
• Materials: Polycarbonate body and float, ABS levers, SEBS membrane

Applications

• Water tank and cistern level control
• Pump protection and cycle reduction
• Replacement for conventional ballcock valves
• Rapid-fill water storage systems
• Agricultural and industrial tank management
