3/8" BSP Female 3-Way T Port Ball Valve, 40 Bar, Brass

Three-way T port ball valve with 3/8" BSP female connections, rated to 40 bar and 80°C.

This compact diverter valve features nickel-chromium plated brass construction for corrosion resistance and durability in demanding applications. The T port configuration allows flow to be directed between three ports, making it ideal for system bypass, circulation, or flow switching duties. PTFE ball seats and Viton seals ensure reliable sealing across the operating range.

Key Features

• 3/8" BSP female thread ports on all three positions
• 40 bar working pressure rating
• Maximum fluid temperature 80°C
• Nickel and chromium plated brass body
• PTFE ball seats for smooth operation
• Viton seals for chemical compatibility

Specifications

• Port size: 3/8" BSP female
• Port configuration: T-shaped (three ports)
• Maximum pressure: 40 bar
• Maximum temperature: 80°C
• Body material: Nickel-chromium plated brass
• Seat material: PTFE
• Seal material: Viton

Applications

• System circulation and flow diversion
• Bypass valve installations
• Multi-circuit hydraulic or pneumatic systems
• Industrial fluid control and routing
• Coolant or lubricant distribution systems
