Description
Compact plated brass lever ball valve with dual 3/8" BSP female connections, designed for reliable on-off flow control in pressurised systems.
This valve combines corrosion-resistant nickel and chromium plating with robust brass construction for durability in demanding environments. The ergonomic lever handle provides quick, intuitive operation, whilst PTFE ball seats ensure a secure seal across the working pressure range.
Key Features
- 3/8" BSP female inlet and outlet connections
- Lever handle for manual operation
- Nickel and chromium plated brass body
- PTFE ball seats for reliable sealing
- Compact 48mm length
- Full bore design for minimal pressure drop
Specifications
- Connection type: 3/8" BSP female × 3/8" BSP female
- Maximum working pressure: 32 bar
- Maximum temperature: 80°C
- Body material: Plated brass
- Seat material: PTFE
- Overall length: 48mm
Applications
- Water and coolant systems in manufacturing and engineering
- Compressed air distribution networks
- Hydraulic fluid control in industrial machinery
- General purpose isolation and flow regulation
- Tank and reservoir outlet control
